Carbon Steel Plate

1045 Cold-Rolled Steel Plate

Name: 1045 Cold-Rolled Steel Plate
Brand: Huaqi Steel

Request 1045 cold-rolled steel plate pricing with thickness, supply condition and machining allowance specified. Send cut sizes, heat-treatment needs, quantity and destination port.

Get a quote for your project

Share your specifications, quantity and destination. Any remaining details can be discussed with our team.

Wholesale and project orders only

We are a China-based steel supplier serving trade and project buyers. Minimum order 5 tonnes; no individual or retail orders.

Your email and order requirements are enough to start.

1045 Cold-Rolled Steel Plate Specifications

1045 Cold Rolled Steel Plate

Carbon steels are a category of steels with 0.12 to 2% carbon content. AISI 1045 is a medium carbon steel designed to be able to function in areas requiring greater strength and hardness. This steel possesses excellent size accuracy, concentricity, and straightness which together enable to minimize wear in high speed applications. AISI 1045 can be formed into turned, ground and polished bars that can be machined unsymmetrically with limited distortion.

The following sections will discuss in detail about AISI 1045 carbon steel.

Product Parameters

Product Name	1045 Cold Rolled Steel Plate
Production Process	Hot Rolling, Cold Rolling
Material Standards	AISI, ASTM, ASME, DIN, BS, EN, ISO, JIS, GOST, SAE, etc.
Width	100mm-3000mm
Length	1m-12m, or Customized Size
Thickness	0.1mm-400mm
Delivery Conditions	Rolling, Annealing, Quenching, Tempered or Standard
Surface Process	Ordinary, Wire Drawing, Laminated Film

Chemical Composition

Element	Content (%)
Carbon, C	0.43-0.50
Manganese, Mn	0.60-0.90
Sulfur, S	0.05 (max)
Phosphorous, P	0.04 (max)
Iron, Fe	Balance

Mechanical Properties

Properties	Metric	Imperial
Tensile strength	585 MPa	84800 psi
Yield strength	450 MPa	65300 psi
Modulus of elasticity	200 GPa	29000 ksi
Shear modulus (typical for steel)	80 GPa	11600 ksi
Poisson’s ratio	0.29	0.29
Elongation at break (in 50 mm)	12%	12%
Hardness, Brinell	163	163
Hardness, Knoop (converted from Brinell hardness)	184	184
Hardness, Rockwell B (converted from Brinell hardness)	84	84
Hardness, Vickers (converted from Brinell hardness)	170	170

Scope of Application

The following are the application areas of AISI 1045 carbon steel:

鈼?Bolts

鈼?Studs

鈼?Gears

鈼?Axles

鈼?Shafts

鈼?Machine parts.

Chemistry, mechanical properties and tolerances should be confirmed against the selected grade and material certificate.

Product Details

Applications

Product Photos

Packaging and Shipment

REQUEST FOR QUOTATION

Discuss 1045 Cold-Rolled Steel Plate

Tell us your required grade, dimensions, order quantity and destination port. Include processing, packing or inspection requirements so we can discuss a suitable supply offer.
