Carbon Steel Coil

1045 Cold-Rolled Steel Coil

Name: 1045 Cold-Rolled Steel Coil
Brand: Huaqi Steel

Source 1045 cold-rolled steel coil with thickness, width and material condition specified. Send heat-treatment and processing requirements, tonnage and destination port for pricing.

Get a quote for your project

Share your specifications, quantity and destination. Any remaining details can be discussed with our team.

Wholesale and project orders only

We are a China-based steel supplier serving trade and project buyers. Minimum order 5 tonnes; no individual or retail orders.

Your email and order requirements are enough to start.

1045 Cold-Rolled Steel Coil Specifications

1045 Cold Rolled Steel Coil

Specify 1045 cold-rolled steel coil by thickness, width and material condition. Agree any heat treatment and downstream processing requirements before selecting coil stock.

Product Parameters

Product Name	1045 Cold Rolled Steel Coil
Production Process	Hot Rolling, Cold Rolling
Material Standards	AISI, ASTM, ASME, DIN, BS, EN, ISO, JIS, GOST, SAE, etc.
Width	100mm-3000mm
Length	1m-12m, or Customized Size
Thickness	0.1mm-400mm
Delivery Conditions	Rolling, Annealing, Quenching, Tempered or Standard
Surface Process	Ordinary, Wire Drawing, Laminated Film

Chemical Composition

Element	Content (%)
Carbon, C	0.43-0.50
Manganese, Mn	0.60-0.90
Sulfur, S	0.05 (max)
Phosphorous, P	0.04 (max)
Iron, Fe	Balance

Mechanical Properties

Properties	Metric	Imperial
Tensile strength	585 MPa	84800 psi
Yield strength	450 MPa	65300 psi
Modulus of elasticity	200 GPa	29000 ksi
Shear modulus (typical for steel)	80 GPa	11600 ksi
Poisson’s ratio	0.29	0.29
Elongation at break (in 50 mm)	12%	12%
Hardness, Brinell	163	163
Hardness, Knoop (converted from Brinell hardness)	184	184
Hardness, Rockwell B (converted from Brinell hardness)	84	84
Hardness, Vickers (converted from Brinell hardness)	170	170

Scope of Application

The following are the application areas of AISI 1045 carbon steel:

鈼?Bolts

鈼?Studs

鈼?Gears

鈼?Axles

鈼?Shafts

鈼廫n Machine parts.

Chemistry, mechanical properties and tolerances should be confirmed against the selected grade and material certificate.

Product Details

Applications

Product Photos

Packaging and Shipment

REQUEST FOR QUOTATION

Discuss 1045 Cold-Rolled Steel Coil

Tell us your required grade, dimensions, order quantity and destination port. Include processing, packing or inspection requirements so we can discuss a suitable supply offer.
